PTG TECHNICAL BULLETIN #1
PITCH RAISING
(revised 8/26/94)
© 1992 & 1994 The Piano Technicians Guild, Inc.
[ Visit the PTG Web Site ]
[ Additional Bulletin Credits ]
Why does a piano's pitch change?
Won't tuning restore my piano's pitch to A-440?
How far from standard pitch must a piano be before a pitch
raise is necessary?
How long does a pitch raise take?
Your piano is designed to sound its best when tuned to A-440 (A above middle
C vibrates at 440 cycles per second), the international pitch standard. At
this pitch, power and tonal range are optimum and your piano will match the
pitch of other instruments. When your piano varies from A-440, pitch adjustments
are required to bring it back to standard. By always maintaining your piano
at standard pitch, you create long-term tuning stability because the strings
and structure stay in equilibrium. You also ensure proper ear training because
you always hear your music in the correct key.
Why does a piano's pitch change?
Piano strings change pitch for two primary reasons: the initial stretching
and settling of strings when the piano is new, and soundboard movement due
to humidity variation. In the case of new pianos, the pitch drops quickly
for the first couple of years as the new strings stretch and wood parts settle.
It's very important to maintain any new piano at the proper pitch during
this period, so the string tension and piano structure can reach a stable
equilibrium. (Most piano manufacturers recommend three to four tunings the
first year, and at least two per year after that.)
Aside from this initial settling, climate change is the main cause of pitch
change. That's because the piano's main acoustical structure -- the soundboard
-- is made of wood. While wooden soundboards produce a wonderful sound, they
also react constantly to climate changes. As the relative humidity goes up,
the soundboard swells, increasing its crowned shape and stretching the piano's
strings to a higher pitch. Then during dry times the soundboard flattens
out, lowering tension on the strings and causing the pitch to drop. The drop
in the dry season tends to exceed the rise during humid times, so the net
result is a drop in pitch each year that the piano isn't serviced.
Go to top
Won't tuning restore my piano's pitch to A- 440?
If a piano has gone without tuning for an extended period, its pitch may
have dropped far below A- 440. This means that each of its approximately
220 strings needs to be tightened considerably, adding tremendous additional
tension to the piano's structure. The problem is that as each string is
tightened, the additional load causes the pitch of previously adjusted strings
to change. Thus it is impossible to make a substantial change in pitch and
end up with a fine, accurate tuning in one step. Instead, a process called
"pitch raising" must first be done, in which all strings are raised to their
correct average tension levels. (Likewise, when a piano's pitch is higher
than standard, a pitch lowering procedure must be done to reduce string tensions
to approximately correct levels.) Only then can the piano be accurately tuned.
In other words, accurate tuning is only possible when all strings are so
close to their proper tension that only small further changes are needed
during tuning. These small changes then do not disturb the tuning of other
strings.
Go to top
How far from standard pitch must a piano be before a pitch
raise is necessary?
Just when a pitch raise or lowering is necessary depends upon how accurate
the final tuning must be, and the size and quality of the piano. Any net
change in a piano's string tension during tuning will distort the final result
and reduce stability. Realistically, a pitch difference of a few percent
can usually be accommodated successfully during tuning. For average situations,
when a piano's pitch is noticeably different from that of other standard
pitched instruments, a pitch correction procedure is necessary before tuning.
Whenever exact pitch level is critical, such as in concert or recording
instruments, any pitch deviation must be corrected before tuning.
Go to top
How long does a pitch raise take?
A pitch raise is essentially a special tuning procedure designed to leave
the piano approximately in tune. For moderate pitch corrections the procedure
takes about the same time as a tuning, or less. Extreme pitch changes may
require two separate pitch adjustments.
The pitch adjustment and subsequent tuning may be done in one visit, or the
tuning may be scheduled for a short time later depending upon how far the
pitch had to be changed. In general, the longer a piano has gone without
regular service, the more tunings will be required to reestablish tuning
stability.
Like your car, your piano is a major investment which deserves regular servicing
to keep it working well and preserve its value. Most importantly, the
well-maintained piano sounds better, plays better, and gives you and your
family a wealth of musical pleasure.
Go to top
The preceding article is a reprint of Technical Bulletin #1 published by
the Piano Technicians Guild, Inc. It is provided on the Internet as a service
to piano owners.
Piano Technicians Guild is an international organization of piano technicians.
Registered Piano Technicians (RPTs) are those members of PTG who have passed
a series of examinations on the maintenance, repair, and tuning of pianos.
For a copy of this or other PTG Bulletins and Pamphlets, or a list of PTG
members in your area, vist the PTG web site or contact Piano Technicians
Guild, Inc., 4444 Forest Ave, Kansas City, KS, 66106. Ph: (913) 432-9975
Fax: (913) 432-9986 E-mail ptg@ptg.org
